Aten KVM Switch CS1182H HDMI Secure1/3
Aten

ATEN 2-Port USB HDMI Secure KVM Switch

Part number
1291356
MPN
CS1182H
EAN
4719264646614

ATEN 2-Port USB HDMI Secure KVM Switch, 3840 x 2160 pixels, 4K Ultra HD, Rack mounting, 2.4 W, 1U, Black

Konsolen Ports3.5 mm Kopfhöreranschluss, HDMI Typ A, PS/2, USB 2.0
Computer Ports3.5 mm Kopfhöreranschluss, HDMI Typ A, USB 2.0
MountingDesktop
KVM-ArtLokal
Power supplyInternes Netzteil
Max. Auflösung3840 x 2160 (Ultra HD 4K)
Number of computers controlled2
Keyboard port typeUSB
All 53 specifications

Description

ATEN 2-Port USB HDMI Secure KVM Switch. Keyboard port type: USB, Mouse port type: USB, Video port type: HDMI. HD type: 4K Ultra HD, Maximum resolution: 3840 x 2160 pixels, Video bandwidth: 30 Hz. Product colour: Black, Rack capacity: 1U. Power source: AC, Input voltage: 100 - 240 V, AC input frequency: 50 - 60 Hz. Compliance certificates: RoHS

Documents

Specifications

Konsolen Ports3.5 mm Kopfhöreranschluss, HDMI Typ A, PS/2, USB 2.0
Computer Ports3.5 mm Kopfhöreranschluss, HDMI Typ A, USB 2.0
MountingDesktop
KVM-ArtLokal
Power supplyInternes Netzteil
Max. Auflösung3840 x 2160 (Ultra HD 4K)

Ports & interfaces

Number of computers controlled2
Keyboard port typeUSB
Mouse port typeUSB
Video port typeHDMI
Console ports3.5mm headphone, HDMI, PS/2, USB A
HDMI ports quantity2
USB 2.0 Type-B ports quantity4
Console USB ports quantity2
USB connector typeUSB Type-B
PS/2 ports quantity2
Audio connectionsYes
Headphone outputs2

Performance

HD type4K Ultra HD
Maximum resolution3840 x 2160 pixels
Video bandwidth30 Hz

Design

Rack mountingYes
Product colourBlack
Rack capacity1U
LED indicatorsYes
Push buttonYes

Display

Built-in displayNo

Power

Power sourceAC
Input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current1 A
Power consumption (typical)2.4 W

Sustainability

Compliance certificatesRoHS

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)0 - 80%

Weight & dimensions

Width335 mm
Depth163.9 mm
Height44 mm
Weight1.95 kg

Packaging data

Package width116 mm
Package depth540 mm
Package height233 mm

Packaging content

Cables includedAC
Quick installation guideYes
ManualYes

Logistics data

Master (outer) case net weight5.85 kg
Harmonized System (HS) code85176200
Master (outer) case width375 mm
Master (outer) case length565 mm
Master (outer) case height258 mm
Master (outer) case gross weight7.37 kg
Products per master (outer) case3 pc(s)
Weight2.27 kg
