Canon imageFORMULA P-208II Portable Duplex Document Scanner

Part number: 337870
MPN: 9704B003
EAN: 4528472106366

Canon imageFORMULA P-208II Portable Duplex Document Scanner, 216 x 356 mm, 600 x 600 DPI, 24 bit, 8 ppm, 6 ppm, 16 ipm

Connectivity	USB
Scanner Funktionen	Duplex-Vorlagenwechsler (D-ADF), Scan von geprägten Karten
Maximales Scanformat	A4
Scangeschwindigkeit Max.	8 Seiten
Empfohlenes Tagesvolumen	100 Seiten
ADF Kapazität	10 Seiten
Maximum scan size	216 x 356 mm
Optical scanning resolution	600 x 600 DPI

Description

Canon imageFORMULA P-208II Portable Duplex Document Scanner. Maximum scan size: 216 x 356 mm, Optical scanning resolution: 600 x 600 DPI, Input colour depth: 24 bit. Scanner type: Sheet-fed scanner, Product colour: Black. Sensor type: CIS, Light source: LED, Scan drivers: ISIS, TWAIN. Standard input capacity: 1 sheets. Maximum ISO A-series paper size: A4, Scanning media types supported: Business Card, Card stock, Plain paper, Post Card(JPN), ISO A-series sizes (A0...A9): A4

Documents

Data sheetPDF · DE

Specifications

Connectivity	USB
Scanner Funktionen	Duplex-Vorlagenwechsler (D-ADF), Scan von geprägten Karten
Maximales Scanformat	A4
Scangeschwindigkeit Max.	8 Seiten
Empfohlenes Tagesvolumen	100 Seiten
ADF Kapazität	10 Seiten

Scanning

Maximum scan size	216 x 356 mm
Optical scanning resolution	600 x 600 DPI
Duplex scanning	Yes
Colour scanning	Yes
Input colour depth	24 bit
Film scanning	No
Greyscale levels	256
ADF scan speed (b/w, A4)	8 ppm
ADF scan speed (colour, A4)	6 ppm
Duplex ADF scan speed (b/w, A4)	16 ipm
Duplex ADF scan speed (colour, A4)	12 ipm
Black/white scanning colour modes	Grayscale

Design

Scanner type	Sheet-fed scanner
Built-in display	No
Product colour	Black

Performance

Sensor type	CIS
Light source	LED
Scan drivers	ISIS, TWAIN

Input capacity

Standard input capacity	1 sheets

Paper handling

Maximum ISO A-series paper size	A4
Scanning media types supported	Business Card, Card stock, Plain paper, Post Card(JPN)
ISO A-series sizes (A0...A9)	A4
Letter	Yes
Auto Document Feeder (ADF) media weight	52 - 380 g/m²
Maximum scan area (ADF)	216 x 356 mm
Minimum scan area (ADF)	50.8 x 70 mm

Ports & interfaces

USB port	Yes
USB version	2.0
Standard interfaces	USB 2.0

Power

Power supply type	USB
Power consumption (typical)	2.5 W
Power consumption (standby)	1.5 W
Power consumption (off)	0.1 W
Current	0.5 A

Weight & dimensions

Width	312.5 mm
Depth	89.5 mm
Height	40 mm
Weight	600 g

Sustainability

Sustainability certificates	ENERGY STAR

System requirements

Windows operating systems supported	Yes
Mac operating systems supported	Yes

Operational conditions

Operating temperature (T-T)	10 - 32.5 °C
Operating relative humidity (H-H)	25 - 80%

Other features

Compliance certificates	RoHS

Logistics data

Harmonized System (HS) code	84716070
Weight	1.02 kg
