COUGAR Power Supply STC 500W ATX / 80 Plus 230V EU

Cougar STC500 500 W1/8
Part number
2209079
MPN
CGR-STC500
EAN
4710483774317

COUGAR Power Supply STC 500W ATX / 80 Plus 230V EU, 500 W, 220 - 240 V, 50 Hz, Active, 110 W, 456 W

80 PLUS Zertifikat80 PLUS (Standard)
PSU Rated Power500 W
PSU Cable TypeFix
Power Supply Form FactorATX
Total Power500 W
AC Input Voltage220 - 240 V
AC input frequency50 Hz
Power Factor Correction (PFC) typeActive
All 39 specifications

Description

COUGAR Power Supply STC 500W ATX / 80 Plus 230V EU. Total power: 500 W, AC input voltage: 220 - 240 V, AC input frequency: 50 Hz. Motherboard power connector: 20+4 pin ATX, Motherboard power cable length: 45 cm, Peripheral (Molex) power cable length: 450 mm. Purpose: PC/Server, 80 PLUS certification: 80 PLUS. Product colour: Black, Cooling type: Active, Fan diameter: 12 cm. Width: 150 mm, Depth: 140 mm, Height: 86 mm

Documents

Specifications

80 PLUS Zertifikat80 PLUS (Standard)
PSU Rated Power500 W
PSU Cable TypeFix
Power Supply Form FactorATX

Power

Total Power500 W
AC Input Voltage220 - 240 V
AC input frequency50 Hz
Power Factor Correction (PFC) typeActive
Combined power (+3.3V)110 W
Combined power (+12V)456 W
Combined power (+5V)110 W
Combined power (-12V)0.3 W
Combined power (+5Vsb)2.5 W
Max output current (+3.3V)16 A
Max output current (+12V)42 A
Power protection featuresOver current, Over power, Over voltage, Short circuit, Under voltage

Ports & interfaces

Motherboard Connector20+4 pin ATX
Motherboard power cable length45 cm
Number of SATA Power Connectors5
Number of PATA power connectors2
Peripheral (Molex) power cable length450 mm
Number of PCI Express Power Connectors 6+2pin2
Cable TypeNon-Modular

Performance

PurposePC/Server
80 PLUS certification80 PLUS

Design

ColourBlack
CoolingActive
Fan Diameter12 cm
Number of Fans1 fan(s)

Weight & dimensions

Width150 mm
Depth140 mm
Height86 mm
Weight1.48 kg

Packaging data

Package width158 mm
Package depth187 mm
Package height165 mm
Package Weight1.76 kg

Logistics data

Country of originChina

Other features

Commodity Classification Automated Tracking System (CCATS)8504401300
Weight1.77 kg
