D-Link Dockingstation DUP-A01 10-In-1 USB-C Hub1/9
D-Link

D-Link 10-in-1 USB-C Hub

Part number
1942679
MPN
DUP-A01
EAN
790069478215

D-Link 10-in-1 USB-C Hub, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, MicroSD (TransFlash), SD, 10000 Mbit/s, 60 Hz, 3860 x 2160

LadefunktionJa
DockinganschlussUSB-C
Kompatible HerstellerUniversal
VESA-Bohrung vorhandenNo
Compatible manufacturersUniversal
Ports quantity10
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-C
Hub interfacesRJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C
All 41 specifications

Description

D-Link 10-in-1 USB-C Hub. Host interface: USB 3.2 Gen 1 (3.1 Gen 1) Type-C, Hub interfaces: RJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C, Compatible memory cards: MicroSD (TransFlash), SD. Data transfer rate: 10000 Mbit/s, Maximum refresh rate: 60 Hz, Supported graphics resolutions: 3860 x 2160. Ethernet interface type: Gigabit Ethernet, Ethernet LAN data rates: 10,100,1000 Mbit/s. Power supply type: USB. Width: 125 mm, Depth: 55.4 mm, Height: 16.6 mm

Documents

Specifications

LadefunktionJa
DockinganschlussUSB-C
Kompatible HerstellerUniversal
VESA-Bohrung vorhandenNo
Compatible manufacturersUniversal

Ports & interfaces

Ports quantity10
Host interfaceUSB 3.2 Gen 1 (3.1 Gen 1) Type-C
Hub interfacesRJ-45, USB 3.2 Gen 1 (3.1 Gen 1) Type-A, USB 3.2 Gen 1 (3.1 Gen 1) Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity2
HDMI ports quantity2
Ethernet LAN (RJ-45) ports1
Card reader slot2
Compatible memory cardsMicroSD (TransFlash), SD

Features

Data transfer rate10000 Mbit/s
Maximum refresh rate60 Hz
Supported graphics resolutions3860 x 2160
Supported video modes2160p
Maximum resolution (HDMI)3840 x 2160 pixels
Product colourWhite
USB Power Delivery (USB PD)Yes
USB Power Delivery revision3.0
USB Power Delivery up to100 W
HD type4K Ultra HD
Plug and PlayYes
CertificationCE, FCC, RCM

Network

Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s

Power

Power supply typeUSB

Weight & dimensions

Width125 mm
Depth55.4 mm
Height16.6 mm
Weight98.5 g

Packaging data

Quantity per pack1 pc(s)

Packaging content

Quick start guideYes

Operational conditions

Minimum operating temperature0 °C
Maximum operating temperature40 °C
Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-20 - 60 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 95%
Weight0.15 kg
