D-Link PoE+ Switch DGS-1510-52XMP 52 Port

Hover to zoom1/5

D-Link 52-Port Gigabit Stackable POE Smart Managed Switch including 4 x 10G SFP+

Part number: 1416406
MPN: DGS-1510-52XMP/E
EAN: 790069467967

D-Link 52-Port Gigabit Stackable POE Smart Managed Switch including 4 x 10G SFP+, Managed, L3, Gigabit Ethernet (10/100/1000), Full duplex, Power over Ethernet (PoE), Rack mounting

SFP Anschlüsse	0
Montage Switch	19" Rack
SFP+ Anschlüsse	4
QSFP+ Anschlüsse	0
SFP28 Anschlüsse	0
Switch Management	Smart-Managed
Switch type	Managed
Switch layer	L3

Description

D-Link 52-Port Gigabit Stackable POE Smart Managed Switch including 4 x 10G SFP+. Switch type: Managed, Switch layer: L3. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 48. Full duplex. MAC address table: 16000 entries, Switching capacity: 128 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x. Power over Ethernet (PoE). Rack mounting

Documents

Data sheetPDF · DE

Specifications

SFP Anschlüsse	0
Montage Switch	19" Rack
SFP+ Anschlüsse	4
QSFP+ Anschlüsse	0
SFP28 Anschlüsse	0
Switch Management	Smart-Managed

Management features

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Web-based management	Yes
Traffic classification	Yes
ARP inspection	Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity	48
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
SFP+ module slots quantity	4

Network

Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x
10G support	Yes
Cable types supported	Cat5, Cat5e
Full duplex	Yes
Auto MDI/MDI-X	Yes

Data transmission

MAC address table	16000 entries
Switching capacity	128 Gbit/s
Throughput	95.24 Mpps
Number of IP interfaces	16
Jumbo frames support	Yes
Jumbo frames	9216

Multicast features

Multicast support	Yes
Multicast MAC address table	512 entries

Design

Rack mounting	Yes
Stackable	Yes
Product colour	Black
Reset button	Yes
LED indicators	Activity, Link, PoE, Speed
Number of fans	3 fan(s)

Performance

Noise level	56.9 dB

Power

Power supply included	Yes
AC input voltage	100 - 240 V
Power consumption (max)	486.9 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)	Yes

Operational conditions

Operating temperature (T-T)	-5 - 50 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	0 - 95%
Storage relative humidity (H-H)	0 - 95%
Heat dissipation	138.787 BTU/h

Weight & dimensions

Width	440 mm
Depth	308 mm
Height	44 mm
Weight	5.41 kg

Packaging data

Package width	475 mm
Package depth	520 mm
Package height	110 mm
Package weight	7.26 kg

Certificates

Certification	CE FCC C-Tick VCCI BSMI cUL CB
Weight	7.20 kg
