Zyxel Switch GS2220-10 10 Port1/5
Zyxel

Zyxel GS2220-10-EU0101F network switch Managed L2 Gigabit Ethernet (10/100/1000) Black

Part number
1097450
MPN
170120
EAN
4718937607365

Zyxel GS2220-10-EU0101F, Managed, L2, Gigabit Ethernet (10/100/1000), Rack mounting

SFP Anschlüsse2
Montage Switch19" Rack, Wand
SFP+ Anschlüsse0
QSFP+ Anschlüsse0
SFP28 Anschlüsse0
Switch ManagementCloud-Managed
Switch typeManaged
Switch layerL2
All 66 specifications

Description

Zyxel GS2220-10-EU0101F. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 10. MAC address table: 16000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE.... Rack mounting

Documents

Specifications

SFP Anschlüsse2
Montage Switch19" Rack, Wand
SFP+ Anschlüsse0
QSFP+ Anschlüsse0
SFP28 Anschlüsse0
Switch ManagementCloud-Managed

Management features

Switch typeManaged
Switch layerL2
Quality of Service (QoS) supportYes
Web-based managementYes
Configuring Location Settings (CLI)Yes
System event logYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity10
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Installed SFP modules quantity0
Installed SFP+ modules quantity0

Network

Networking standardsIEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
10G supportNo
Copper ethernet cabling technology10BASE-TX, 1000BASE-T
Flow control supportYes
Link aggregationYes
Broadcast storm controlYes
Rate limitingYes
Spanning tree protocolYes
VLAN supportYes
Virtual LAN featuresPort-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN

Data transmission

MAC address table16000 entries
Switching capacity20 Gbit/s
Forwarding rate15 Mpps
Packet buffer memory1.5 MB

Security

DHCP featuresDHCP client, DHCP relay, DHCP snooping, DHCPv6 client, DHCPv6 relay
Access Control List (ACL)Yes
IGMP snoopingYes
Security algorithmsSNMP, SNMPv2, SNMPv3, SSH-2, SSL/TLS
MAC address filteringYes
AuthenticationGuest VLAN, MAC-based authentication
Authentication typeIEEE 802.1x, RADIUS

Multicast features

Multicast supportYes

Design

Rack mountingYes
Product colourBlack

Performance

Internal memory256 MB
Flash memory32 MB
Noise level0 dB
Firmware upgradeableYes
FanlessYes
Mean time between failures (MTBF)1213492 h

Power

AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)11 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)0 - 50 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 95%
Storage relative humidity (H-H)10 - 95%
Heat dissipation37.51 BTU/h

Weight & dimensions

Width267 mm
Depth162 mm
Height44 mm
Weight1.3 kg

Packaging content

Cables includedAC

Packaging data

Package width375 mm
Package depth235 mm
Package height61 mm
Package weight2.21 kg

Certificates

CertificationLVD, BSMI FCC 15 A, CE EMC A, BSMI ENC RoHS A

Logistics data

Harmonized System (HS) code85176990
Weight2.19 kg
