be quiet! Wasserkühlung Light Loop 240 LCD

Hover to zoom1/7

be quiet! Light Loop IO LCD 240 mm White

Part number: 2213340
MPN: BW035
EAN: 4260052193259

be quiet! Light Loop IO LCD 240 mm White, All-in-one liquid cooler, 12 cm, 105.1 m³/h, White

Processor socket	AM4, AM5, LGA 1150, LGA 1151, LGA 1155, LGA 1200, LGA 1700, LGA 1851
Radiatorgrösse	240 mm
Suitable location	Processor
Type	All-in-one liquid cooler
Fan diameter	12 cm
Supported processor sockets	LGA 1851, LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5
Compatible processor series	AMD Ryzen 9000 Series, Intel® Core™ i9
Noise level (low speed)	15.4 dB

Description

be quiet! Light Loop IO LCD 240 mm White. Type: All-in-one liquid cooler, Fan diameter: 12 cm, Airflow: 105.1 m³/h, Maximum air pressure: 2.51 mmH2O, Bearing type: Rifle bearing. Height: 52 mm. Product colour: White

Documents

Specifications

Processor socket	AM4, AM5, LGA 1150, LGA 1151, LGA 1155, LGA 1200, LGA 1700, LGA 1851
Radiatorgrösse	240 mm

Performance

Suitable location	Processor
Type	All-in-one liquid cooler
Fan diameter	12 cm
Supported processor sockets	LGA 1851, LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1200 (Socket H5), LGA 1700, Socket AM4, Socket AM5
Compatible processor series	AMD Ryzen 9000 Series, Intel® Core™ i9
Noise level (low speed)	15.4 dB
Noise level (high speed)	34.9 dB
Maximum airflow	61.8 cfm
Airflow	105.1 m³/h
Maximum air pressure	2.51 mmH2O
Pulse-width modulation (PWM) support	Yes
Bearing type	Rifle bearing
Pump connector	4-pin
Quantity per pack	1 pc(s)
Pump motor speed	2900 RPM
Pump motor speed (min)	1500 RPM
Pump motor speed (max)	2900 RPM
Fan speed (max)	2100 RPM
Fan's mean time to failure (MTTF)	60000 h

Design

Product colour	White
Radiator material	Aluminum
Base plate material	Copper
Number of fans	2 fan(s)
Number of fan blades	9
Illumination LED	Yes
Illumination colour	Multi
Display type	Not applicable
Daisy chain	Yes

Power

Fan power consumption	5.4 W
Fan voltage	12 V
Fan current	0.17 A

Weight & dimensions

Height	52 mm
Radiator width	12 cm
Radiator depth	27.7 cm
Radiator height	2.7 cm
Tube length	40 cm
Waterblock width	6.19 cm
Waterblock depth	6.38 cm
Waterblock height	5.4 cm
Weight	1.05 kg
Fan dimensions (W x D x H)	120 x 120 x 25 mm
Package width	205 mm
Package depth	322 mm
Package height	137 mm
Package weight	2.54 kg

Technical details

Doesn't contain	Cadmium, Lead, Mercury
Warranty period	3 year(s)
Compliance certificates	CE, Federal Communications Commission (FCC), RoHS, UKCA

Certificates

Waste Electrical and Electronic Equipment (WEEE) compliance	Yes

Packaging content

Package type	Box
Mounting kit	Yes
Manual	Yes

Other features

Thermal grease	Yes
Weight	2.19 kg
