TP-Link Switch Omada Unmanaged 8 x 2.5G Ports TL-SG108-M2 8 Port

Hover to zoom1/4

TP-Link 8-Port 2.5G Desktop Switch

Part number: 1227604
MPN: TL-SG108-M2
EAN: 1210002612678

TP-Link 8-Port 2.5G Desktop Switch, Unmanaged, 2.5G Ethernet (100/1000/2500), Wall mountable

SFP Anschlüsse	0
Montage Switch	Desktop, Wand
SFP+ Anschlüsse	0
QSFP+ Anschlüsse	0
SFP28 Anschlüsse	0
Switch Management	Unmanaged
Switch type	Unmanaged
Quality of Service (QoS) support	Yes

Description

TP-Link 8-Port 2.5G Desktop Switch. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: 2.5G Ethernet (100/1000/2500), Basic switching RJ-45 Ethernet ports quantity: 8. MAC address table: 16000 entries, Switching capacity: 40 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x. Wall mountable

Documents

Data sheetPDF · DE

Specifications

SFP Anschlüsse	0
Montage Switch	Desktop, Wand
SFP+ Anschlüsse	0
QSFP+ Anschlüsse	0
SFP28 Anschlüsse	0
Switch Management	Unmanaged

Management features

Switch type	Unmanaged
Quality of Service (QoS) support	Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity	8
Basic switching RJ-45 Ethernet ports type	2.5G Ethernet (100/1000/2500)
Installed SFP modules quantity	0
Installed SFP+ modules quantity	0
2.5G Ethernet (copper) ports quantity	8

Network

Networking standards	IEEE 802.3, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3p, IEEE 802.3u, IEEE 802.3x
10G support	No
Flow control support	Yes
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes

Data transmission

MAC address table	16000 entries
Switching capacity	40 Gbit/s
Forwarding rate	29.8 Mpps
Store-and-forward	Yes
Jumbo frames support	Yes
Jumbo frames	10000
Packet buffer memory	1.5 MB

Design

Rack mounting	No
Product colour	Black
LED indicators	Yes
Wall mountable	Yes

Performance

Fanless	Yes

Power

Power source	DC
Power supply included	Yes
Input current	1.5 A
Input voltage	12 V

Power over Ethernet (PoE)

Power over Ethernet (PoE)	No

Operational conditions

Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Heat dissipation	53.4 BTU/h

Weight & dimensions

Width	226 mm
Depth	131 mm
Height	35 mm

Packaging content

Cables included	AC, LAN (RJ-45)

Packaging data

Package width	240 mm
Package depth	315 mm
Package height	70 mm
Package weight	1.35 kg

Logistics data

Harmonized System (HS) code	85176990
Weight	0.56 kg
