TP-Link SFP+ Switch SX6632YF 32 Port1/5
TP-Link

TP-Link Omada SX6632YF network switch Managed L2+/L3 Black

Part number
1812681
MPN
SX6632YF
EAN
4895252501315

TP-Link Omada SX6632YF, Managed, L2+/L3, Rack mounting

SFP Anschlüsse0
Montage Switch19" Rack
SFP+ Anschlüsse26
QSFP+ Anschlüsse0
SFP28 Anschlüsse6
Switch ManagementCloud-Managed
Switch typeManaged
Switch layerL2+/L3
All 60 specifications

Description

TP-Link Omada SX6632YF. Switch type: Managed, Switch layer: L2+/L3. Console port: RJ-45. MAC address table: 128000 entries, Switching capacity: 820 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3ah. Rack mounting

Documents

Specifications

SFP Anschlüsse0
Montage Switch19" Rack
SFP+ Anschlüsse26
QSFP+ Anschlüsse0
SFP28 Anschlüsse6
Switch ManagementCloud-Managed

Management features

Switch typeManaged
Switch layerL2+/L3
Quality of Service (QoS) supportYes
Web-based managementYes
Cloud-managedYes
ARP inspectionYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports typeNo
SFP module slots quantity6
SFP+ module slots quantity26
USB Type-A ports quantity2
USB Type-C ports quantity1
Number of management ports1 pc(s)
Console portRJ-45

Network

Networking standardsIEEE 802.1Q, IEEE 802.1ad, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3ah
10G supportYes
Port mirroringYes
IP routingYes
VLAN supportYes
Virtual LAN featuresMAC address-based VLAN, Multicast VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN

Data transmission

MAC address table128000 entries
Switching capacity820 Gbit/s
Forwarding rate610.1 Mpps
Jumbo frames supportYes
Jumbo frames9000
Packet buffer memory8 MB

Security

DHCP featuresDHCP Option 82
Access Control List (ACL)Yes
IGMP snoopingYes
MAC address filteringYes
Static port securityYes
SSH/SSL supportYes

Multicast features

Multicast supportYes

Protocols

Management protocolsSNMPv1/v2c/v3

Design

Rack mountingYes
StackableYes
Product colourBlack
Number of fans4 fan(s)

Performance

Minimum system requirementsMicrosoft® Windows® 98SE, NT, 2000, XP, Vista™ / Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® /Linux.

Power

Power sourceAC
Redundant power supply (RPS) supportYes
Number of power supply units2
AC input voltage100 - 240 V
AC input frequency50/60 Hz

Power over Ethernet (PoE)

Power over Ethernet (PoE)No

Operational conditions

Operating temperature (T-T)-5 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%

Weight & dimensions

Width440 mm
Depth380 mm
Height44 mm

Packaging content

Cables includedPower
Quick start guideYes
Rack mount kitYes
Weight11.72 kg
