TP-Link Switch Omada Easy Smart 24 x 1G Ports TL-SG1024DE 24 Port1/5
TP-Link

TP-Link TL-SG1024DE network switch Managed L2 Gigabit Ethernet (10/100/1000) Black

Part number
255613
MPN
TL-SG1024DE
EAN
1210002616812

TP-Link TL-SG1024DE, Managed, L2, Gigabit Ethernet (10/100/1000), Full duplex, Rack mounting

SFP Anschlüsse0
Montage Switch19" Rack
SFP+ Anschlüsse0
QSFP+ Anschlüsse0
SFP28 Anschlüsse0
Switch ManagementSmart-Managed
Switch typeManaged
Switch layerL2
All 54 specifications

Description

TP-Link TL-SG1024DE. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 8000 entries, Switching capacity: 48 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u. Rack mounting

Documents

Specifications

SFP Anschlüsse0
Montage Switch19" Rack
SFP+ Anschlüsse0
QSFP+ Anschlüsse0
SFP28 Anschlüsse0
Switch ManagementSmart-Managed

Management features

Switch typeManaged
Switch layerL2
Quality of Service (QoS) supportYes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports typeGigabit Ethernet (10/100/1000)
Installed SFP modules quantity0
Installed SFP+ modules quantity0

Network

Networking standardsIEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u
10G supportNo
Copper ethernet cabling technology10BASE-T, 100BASE-TX, 1000BASE-T
Port mirroringYes
Full duplexYes
Flow control supportYes
Link aggregationYes
Broadcast storm controlYes
Rate limitingYes
Auto MDI/MDI-XYes
Number of VLANs32

Data transmission

MAC address table8000 entries
Switching capacity48 Gbit/s
Throughput35.7 Mpps
Store-and-forwardYes
Number of queues4
Jumbo frames supportYes
Jumbo frames10000
Packet buffer memory4.1 MB

Security

IGMP snoopingYes

Design

Rack mountingYes
Product colourBlack
LED indicatorsYes

Power

Power supply includedYes
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (typical)14.19 W

Operational conditions

Operating temperature (T-T)0 - 40 °C
Storage temperature (T-T)-40 - 70 °C
Operating relative humidity (H-H)10 - 90%
Storage relative humidity (H-H)5 - 90%
Heat dissipation48.39 BTU/h

Weight & dimensions

Width294 mm
Depth180 mm
Height44 mm

Packaging content

Cables includedAC
User guideYes
Rack mount kitYes

Packaging data

Package typeBox

Certificates

CertificationFCC, CE, RoHS

Logistics data

Harmonized System (HS) code85176990
Weight2.08 kg
