TP-Link PoE+ Switch 10 x 1G Ports TL-SG1210P 9 Port

Hover to zoom1/5

TP-Link TL-SG1210P network switch Unmanaged Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

Part number: 1043361
MPN: TL-SG1210P
EAN: 1210002617062

TP-Link TL-SG1210P, Unmanaged, Gigabit Ethernet (10/100/1000), Power over Ethernet (PoE), Wall mountable

SFP Anschlüsse	1
Montage Switch	Wand
SFP+ Anschlüsse	0
QSFP+ Anschlüsse	0
SFP28 Anschlüsse	0
Switch Management	Unmanaged
Switch type	Unmanaged
Quality of Service (QoS) support	Yes

Description

TP-Link TL-SG1210P. Switch type: Unmanaged. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 9. MAC address table: 4000 entries, Switching capacity: 20 Gbit/s. Networking standards: IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x. DC input voltage: 53.5 V. Power over Ethernet (PoE). Wall mountable

Documents

Data sheetPDF · DE

Specifications

SFP Anschlüsse	1
Montage Switch	Wand
SFP+ Anschlüsse	0
QSFP+ Anschlüsse	0
SFP28 Anschlüsse	0
Switch Management	Unmanaged

Management features

Switch type	Unmanaged
Quality of Service (QoS) support	Yes

Ports & interfaces

Basic switching RJ-45 Ethernet ports quantity	9
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Gigabit Ethernet (copper) ports quantity	9
SFP module slots quantity	1

Network

Networking standards	IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x
10G support	No
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Auto MDI/MDI-X	Yes
Auto-negotiation	Yes
MAC address auto-learning supported	Yes
MAC address auto-aging supported	Yes

Optical fiber

Fiber ethernet cabling technology	1000BASE-X
Fiber type	Single-mode

Data transmission

MAC address table	4000 entries
Switching capacity	20 Gbit/s
Store-and-forward	Yes

Security

IGMP snooping	Yes

Design

Product colour	Grey
Housing material	Metal
LED indicators	Yes
Wall mountable	Yes

Performance

Fanless	Yes

Power

Power supply included	No
DC input voltage	53.5 V
Input current	1.31 A
Power consumption (typical)	7.11 W
Power consumption (max)	78.13 W

Power over Ethernet (PoE)

Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	8
Total Power over Ethernet (PoE) budget	63 W

Operational conditions

Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	5 - 90%
Heat dissipation	266.42 BTU/h

Weight & dimensions

Width	209 mm
Depth	126 mm
Height	26 mm

Packaging content

Cables included	AC
Quick start guide	Yes
User guide	Yes
Manual	Yes

Certificates

Certification	CE, FCC, RoHS

Logistics data

Harmonized System (HS) code	85176990
Weight	1.24 kg
