Yamaha A-S701 Silver
- Part number
- 321183
- MPN
- AS701-SI
- EAN
- 4957812573795
Yamaha A-S701 Silver, 2.1 channels, 160 W, 0.019%, 104 dB, 100 W, 200 mV
| Radio Tuner | Kein Tuner |
|---|---|
| Detail colour | Silver |
| Audioausgänge | 6,3-mm-Klinke, Lautsprecher, Subwoofer Pre-Out, USB |
| Audioeingänge | Cinch, Digital koaxial, Toslink |
| Audio output channels | 2.1 channels |
| Peak power per channel | 160 W |
| Total Harmonic Distortion (THD) | 0.019% |
| Signal-to-Noise Ratio (SNR) | 104 dB |
Description
Yamaha A-S701 Silver. Audio output channels: 2.1 channels, Peak power per channel: 160 W, Total Harmonic Distortion (THD): 0.019%. Speakers connectivity type: Binding post, Speaker selector: A / B / A+B. Power source type: AC, AC input voltage: 230 V, AC input frequency: 50 Hz. Width: 435 mm, Depth: 387 mm, Height: 151 mm
Documents
Specifications
| Radio Tuner | Kein Tuner |
|---|---|
| Detail colour | Silver |
| Audioausgänge | 6,3-mm-Klinke, Lautsprecher, Subwoofer Pre-Out, USB |
| Audioeingänge | Cinch, Digital koaxial, Toslink |
Audio
| Audio output channels | 2.1 channels |
|---|---|
| Peak power per channel | 160 W |
| Total Harmonic Distortion (THD) | 0.019% |
| Signal-to-Noise Ratio (SNR) | 104 dB |
| Damping factor | 240 |
| RMS power output per channel (8 Ohm) | 100 W |
| Input sensitivity | 200 mV |
| Output level | 3500 mV |
| Input impedance | 47000 Ω |
| Output impedance | 1200 Ω |
| Frequency range | 10 - 50000 Hz |
Ports & interfaces
| Speakers connectivity type | Binding post |
|---|---|
| USB 2.0 ports quantity | 0 |
| Audio (L/R) in | 8 |
| Audio (L/R) out | 2 |
| DC-in jack | Yes |
| Binding post ports quantity | 8 |
| AC (power) in | Yes |
| Digital audio optical in | 1 |
| Digital audio optical out | 1 |
| Digital audio coaxial in | 1 |
| Digital audio coaxial out | 1 |
| Speaker selector | A / B / A+B |
| Line inputs (RCA) | 16 |
| Phono audio in (L,R) | Yes |
| Tuner audio in (L,R) | Yes |
| Tuner audio in (L,R) | Yes |
| Ethernet LAN (RJ-45) ports | 0 |
| Microphone in | Yes |
| Subwoofer out | 1 |
Technical details
| Purpose | Home |
|---|---|
| Connectivity technology | Wired |
| Wi-Fi | No |
| Bluetooth | No |
| Bluetooth version | Not applicable |
| AirPlay | No |
| Volume control | Rotary |
| Bass adjustment | Yes |
| Treble adjustment | Yes |
| On/off switch | Yes |
| Source Direct function | Yes |
| Turntable connectivity | Yes |
| Ethernet LAN | No |
| HDMI | No |
Display
| Built-in display | Yes |
|---|
Power
| Power source type | AC |
|---|---|
| AC input voltage | 230 V |
| AC input frequency | 50 Hz |
| Power consumption (typical) | 270 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (max) | 580 W |
Weight & dimensions
| Width | 435 mm |
|---|---|
| Depth | 387 mm |
| Height | 151 mm |
| Weight | 11.2 kg |
Indication
| LED indicators | Yes |
|---|
Packaging content
| Remote control included | Yes |
|---|---|
| Weight | 14.00 kg |
