ATEN KN2124VB-AX-G KVM switch Rack mounting Metallic
RJ-45 · Rack Montage · Netzwerk
on order
CHF 12,496.76
CHF 8,330.43
CHF 9,005.20 incl. VAT
1/4Aten
All 51 specifications
ATEN KN2124VB-AX-G KVM switch Rack mounting Metallic
- Part number
- 2004239
- MPN
- KN2124VB
- EAN
- 4710469342264
ATEN KN2124VB-AX-G, 1920 x 1200 pixels, Ethernet LAN, Rack mounting, 33 W, 1U, Metallic
| Konsolen Ports | 3.5 mm Kopfhöreranschluss, 3.5 mm Mikrofoneingang, HDMI Typ A, USB 2.0, VGA |
|---|---|
| Computer Ports | RJ-45 |
| Mounting | Rack Montage |
| KVM-Art | Netzwerk |
| Power supply | Mains powered |
| Max. Auflösung | 1920 x 1200 (WUXGA) |
| Number of computers controlled | 24 |
| Keyboard port type | USB, PS/2 |
Description
ATEN KN2124VB-AX-G. Keyboard port type: USB, PS/2, Mouse port type: USB, PS/2, Video port type: HDMI/VGA. Cabling technology: 10/100/1000Base-T(X), Security algorithms: FIPS 140-2. Maximum resolution: 1920 x 1200 pixels, Video bandwidth: 60 Hz, Scan interval: 255 s. Product colour: Metallic, Rack capacity: 1U, Housing material: Metal. Input voltage: 100-240 V, AC input frequency: 50 - 60 Hz, Input current: 1 A
Documents
Specifications
| Konsolen Ports | 3.5 mm Kopfhöreranschluss, 3.5 mm Mikrofoneingang, HDMI Typ A, USB 2.0, VGA |
|---|---|
| Computer Ports | RJ-45 |
| Mounting | Rack Montage |
| KVM-Art | Netzwerk |
| Power supply | Mains powered |
| Max. Auflösung | 1920 x 1200 (WUXGA) |
Ports & interfaces
| Number of computers controlled | 24 |
|---|---|
| Keyboard port type | USB, PS/2 |
| Mouse port type | USB, PS/2 |
| Video port type | HDMI/VGA |
| Console ports | HDMI, USB A, VGA (D-Sub) |
| VGA (D-Sub) ports quantity | 1 |
| Console USB ports quantity | 2 |
| Console HDMI ports quantity | 1 |
| USB 2.0 Type-A hub ports quantity | 4 |
| USB connector type | Mini-USB, USB Type-A |
| Serial port type | RJ-45 |
| Serial ports quantity | 1 |
| Audio connections | Yes |
| Headphone outputs | 1 |
| Number of microphone inputs | 1 |
| DC-in jack | Yes |
Network
| Ethernet LAN | Yes |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| Cabling technology | 10/100/1000Base-T(X) |
| Security algorithms | FIPS 140-2 |
Performance
| Maximum resolution | 1920 x 1200 pixels |
|---|---|
| Video bandwidth | 60 Hz |
| Scan interval | 255 s |
| Number of users | 3 user(s) |
Design
| Rack mounting | Yes |
|---|---|
| Product colour | Metallic |
| Rack capacity | 1U |
| Housing material | Metal |
| LED indicators | Link, Power |
| Push button | Yes |
| Hot keys | No |
Display
| Built-in display | No |
|---|
Power
| Input voltage | 100-240 V |
|---|---|
| AC input frequency | 50 - 60 Hz |
| Input current | 1 A |
| Power consumption (typical) | 33 W |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Storage temperature (T-T) | -20 - 60 °C |
| Operating relative humidity (H-H) | 0 - 80% |
Weight & dimensions
| Width | 433.6 mm |
|---|---|
| Depth | 412.1 mm |
| Height | 44 mm |
| Weight | 5.2 kg |
Logistics data
| Harmonized System (HS) code | 84718000 |
|---|---|
| Country of origin | Taiwan |
| Weight | 3.89 kg |
